Brand: Baldor
SKU: EM2238
Baldor EM2238, U-Frame Motor, 10 HP, 230/460 Volts, 9.4 Amps, 3 Phase, 60 Hz, 3470 RPM, TEFC Enclosure, 256U Frame, Standard, 0936M Motor Type, Cast Iron Frame
Baldor U-Frame Motor
The Baldor U-Frame Motor is designed for applications that require U- frame motor dimensions.
Features
- Steel or cast iron frames
- Single or three phase
Application
- Pump
- Fans
- Conveyors
- Machine Tool
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor EM2238, U-Frame Motor, 10 HP, 230/460 Volts, 9.4 Amps, 3 Phase, 60 Hz, 3470 RPM, TEFC Enclosure, 256U Frame, Standard, 0936M Motor Type, Cast Iron Frame | 1 | $5,031.95/each |
Description
Baldor U-Frame Motor
The Baldor U-Frame Motor is designed for applications that require U- frame motor dimensions.
Features
- Steel or cast iron frames
- Single or three phase
Application
- Pump
- Fans
- Conveyors
- Machine Tool
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | EM2238 |
| Product Type | U-Frame Motor |
| Horsepower | 10 HP |
| Voltage | 230/460 Volts |
| Phase | 3 |
| Frequency | 60 Hz |
| Synchronous Speed | 1800 RPM |
| Speed | 1775 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 9.4 Amps |
| Enclosure | TEFC |
| Frame Size | 256U |
| Motor Type | 0936M |
| Motor Standards | NEMA |
| Number of Poles | 4 |
| Pulley Face Code | Standard |
| Frame Material | Cast Iron |
| Motor Lead Quantity/Wire Size | 9 @ 12 AWG |
| Overall Length | 23.03 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 91.70% |
| Duty Rating | CONT |
| Inverter Code | Inverter ready |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Current | 27.0 A @ 208 V, 26.0 A @ 230 V, 13.0 A @ 460 V |
| Design Code | A |
| Drip Cover | No Drip Cover |
| Heater Indicator | No heater |
| KVA Code | K |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | None |
| Shaft Diameter | 1.375 in |
| Insulation Class | F |
| Power Factor | 78 |
| Pulley End Bearing Type | Ball |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | Shaft Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | No |
| Thermal Device - Winding | None |
| Ambient Temperature | 40 °C |
| Agency Approvals | CSA, CSA, EEV, UR |
