Brand: Little Giant
SKU: 581012
Little Giant 581012, Model TE-3-MD , Magnetic Drive Pump, 1/20 HP, 230 Volts, 1/2" MNPT Discharge, 16.1 ft. Shut Off Head, 6 ft. Cord
Little Giant TE-3-MD Magnetic Drive Pump
This is a magnetic drive pump for non-submersible, in-line use.
Features
- 1/20 hp TEFC motor
- Glass-filled polypropylene magnet housing
- Glass-filled polypropylene volute
- 1.1 specific gravity
- Nitrile O-ring
- Titanium thrust washers and shaft
- C-cCSAus listed
Application
- Circulation of mildly corrosive acids, alkalis, solvents, brine, plating solutions, sterile solutions, and other mildly corrosive chemicals and solutions that are compatible with the pump's material of construction.
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Little Giant 581012, Model TE-3-MD , Magnetic Drive Pump, 1/20 HP, 230 Volts, 1/2" MNPT Discharge, 16.1 ft. Shut Off Head, 6 ft. Cord | 1 | $452.15/each |
Description
Little Giant TE-3-MD Magnetic Drive Pump
This is a magnetic drive pump for non-submersible, in-line use.
Features
- 1/20 hp TEFC motor
- Glass-filled polypropylene magnet housing
- Glass-filled polypropylene volute
- 1.1 specific gravity
- Nitrile O-ring
- Titanium thrust washers and shaft
- C-cCSAus listed
Application
- Circulation of mildly corrosive acids, alkalis, solvents, brine, plating solutions, sterile solutions, and other mildly corrosive chemicals and solutions that are compatible with the pump's material of construction.
Specifications
| Brand | Little Giant |
| Mfg. Number | 581012 |
| Model | TE-3-MD |
| Product Type | Magnetic Drive |
| Application | Mild corrosives circulation |
| Horsepower | 1/20 HP |
| Voltage | 230 volts |
| Current | 0.8 Amps |
| Power | 115 Watts |
| Pressure | 7 PSI |
| Frequency | 60 Hz |
| Suction Connection | 1/2" FNPT |
| Discharge Connection | 1/2" MNPT |
| Maximum Head | 16.1 ft. |
| Flow @ 1ft. | 9.8 GPH |
| Flow @ 3ft. | 9.1 GPH |
| Flow @ 6ft. | 7.8 GPH |
| Flow @ 9ft. | 5.7 GPH |
| Flow @ 15ft. | 2.5 GPH |
| Impeller Material | Glass-filled polypropylene & ceramagnet "A" |
| Pump Housing Material | Glass-filled polypropylene magnet |
| Max. Temperature (Continuous) | 150°F |
| Height | 4.3 in. |
| Length | 8.5 in. |
| Width | 4 in. |
| Cord Length | 6 ft. |
