Picture is illustrative and may not reflect the actual product

Brand: Grundfos

SKU: 96523104

Grundfos 96523104, Model CRN 10-2, CRN 10 Series, Vertical Multistage Centrifugal Pump, 1-1/2 HP, 208-230/460 Volts, 3 Phase, 3480 RPM, 2 Stages, 2" NPT Suction, 2" NPT Discharge, 69.26 GPM Max., 94.55 ft Max. Head, 316 Stainless steel, HQQE Shaft Seal, T

Write a Review
Grundfos
  $5,073.47
Available For Order! (Ships Direct From Manufacturer)
Call Sales Counter !
Free Shipping

Grundfos CRN 10 Vertical Multistage Centrifugal Pump Unit

This Complete Unit Multistage Centrifugal Pump is a vertical multistage centrifugal pump. The in-line design enables the pump to be installed in a horizontal one-pipe system where the suction and discharge ports are in the same horizontal plane and have the same pipe dimensions. This design provides a more compact pump design and pipe work.



Features:

  • It consists of CRI pump unit
  • This pump unit consists of optimized hydraulics, various types of connections, an outer sleeve, a top and various other parts
  • The functionalities are designed for specific pump applications
  • A compact system with a basic CRI pump range which can be applied in almost any industrial solutions
  • The pump end is tested as a complete unit in the factory

Applications:

  • Industrial processing systems
  • Washing and cleaning systems
  • Pumping of acids and alkalis
  • Filtration systems
  • Water pressure boosting
  • Water treatment
  • HVAC
  • Irrigation



Note: Picture is illustrative and may not reflect the actual product.

Key Features:

Brand
Grundfos
Mfg. Number
96523104
Model
CRN 10-2
Stages
2
Construction Material
316 Stainless steel
Impeller Material
316 Stainless steel
Description

Grundfos CRN 10 Vertical Multistage Centrifugal Pump Unit

This Complete Unit Multistage Centrifugal Pump is a vertical multistage centrifugal pump. The in-line design enables the pump to be installed in a horizontal one-pipe system where the suction and discharge ports are in the same horizontal plane and have the same pipe dimensions. This design provides a more compact pump design and pipe work.



Features:

  • It consists of CRI pump unit
  • This pump unit consists of optimized hydraulics, various types of connections, an outer sleeve, a top and various other parts
  • The functionalities are designed for specific pump applications
  • A compact system with a basic CRI pump range which can be applied in almost any industrial solutions
  • The pump end is tested as a complete unit in the factory

Applications:

  • Industrial processing systems
  • Washing and cleaning systems
  • Pumping of acids and alkalis
  • Filtration systems
  • Water pressure boosting
  • Water treatment
  • HVAC
  • Irrigation



Note: Picture is illustrative and may not reflect the actual product.

Specifications
Brand Grundfos
Mfg. Number 96523104
Model CRN 10-2
Series CRN 10
Product Type Vertical Multistage Centrifugal Pump
Application Water treatment, irrigation
Horsepower 1-1/2 HP
NEMA Size 56C
Voltage 208-230/460 Volts
Phase 3
Frequency 60HZ
RPM 3480 RPM
Shaft Seal Type HQQE
Stages 2
Construction Material 316 Stainless steel
Impeller Material 316 Stainless steel
Motor Cooling Type TEFC
Motor Type 80CA
Max. Water Temperature 250°F
Suction 2" NPT
Discharge 2" NPT
Maximum Total Head 94.55 ft
Maximum Flow 69.26 GPM
Weight 70.6 lb
Manuals
Grundfos_96523104_Crcre_Vertical_Multistage_Variable_Speed_System_Leaflet.pdf Grundfos_96523104_Crcre_Vertical_Multistage_Variable_Speed_System_Leaflet.pdf
Grundfos_96523104_Crn10-h_CR_Service_Manual.pdf Grundfos_96523104_Crn10-h_CR_Service_Manual.pdf
Grundfos_96523104_Crn15-h_CR_Service_Manual.pdf Grundfos_96523104_Crn15-h_CR_Service_Manual.pdf
Grundfos_96523104_Crn1_Hs_Service_Manual.pdf Grundfos_96523104_Crn1_Hs_Service_Manual.pdf
Grundfos_96523104_Crn20-h_CR_Service_Manual.pdf Grundfos_96523104_Crn20-h_CR_Service_Manual.pdf
Grundfos_96523104_Crn3-h_Industrial_Service_Manual.pdf Grundfos_96523104_Crn3-h_Industrial_Service_Manual.pdf
Grundfos_96523104_Crn5-h_Industrial_Service_Manual.pdf Grundfos_96523104_Crn5-h_Industrial_Service_Manual.pdf
Grundfos_96523104_CRN_Pump_Model_Gs_Product_Brochure.pdf Grundfos_96523104_CRN_Pump_Model_Gs_Product_Brochure.pdf
Grundfos_96523104_CR_CRI_CRN_10_15_20_Dismantling_Reassembly_Service_Manual.pdf Grundfos_96523104_CR_CRI_CRN_10_15_20_Dismantling_Reassembly_Service_Manual.pdf
Grundfos_96523104_CR_CRI_CRN_CRT_Cre_Crie_Crne_Crte_Custom-built_Pumps_Data_Booklet.pdf Grundfos_96523104_CR_CRI_CRN_CRT_Cre_Crie_Crne_Crte_Custom-built_Pumps_Data_Booklet.pdf
Grundfos_96523104_CR_CRI_CRN_CRT_I_O_Instructions.pdf Grundfos_96523104_CR_CRI_CRN_CRT_I_O_Instructions.pdf
Grundfos_96523104_CR_CRI_CRN_Vertical_Multistage_Centrifugal_Pumps_Data_Booklet.pdf Grundfos_96523104_CR_CRI_CRN_Vertical_Multistage_Centrifugal_Pumps_Data_Booklet.pdf
Grundfos_96523104_CR_CRN_30_60_Dismantling_Reassembly.pdf Grundfos_96523104_CR_CRN_30_60_Dismantling_Reassembly.pdf
Grundfos_96523104_CR_CRN_Quick_Ship_Program_Product_Brochure.pdf Grundfos_96523104_CR_CRN_Quick_Ship_Program_Product_Brochure.pdf
Grundfos_96523104_CR_Reading_The_Pump_Nameplate.pdf Grundfos_96523104_CR_Reading_The_Pump_Nameplate.pdf
Grundfos_96523104_Water_Treatment_Brewery_Case_Story.pdf Grundfos_96523104_Water_Treatment_Brewery_Case_Story.pdf
