Brand: Baldor
SKU: EM3219T-8
Baldor EM3219T-8, General Purpose Motor, 7-1/2 HP, 200 Volts, 20.0 Amps, 3 Phase, 3600 RPM, OPSB Enclosure, 184T Frame, Standard, Foot Mounted, 3632M Motor Type, Steel Frame
Baldor Super-E Premium Efficient Totally Open General Purpose Motor
This motor is designed to meet or exceed the energy efficiency requirements of the United States for general purpose industrial motors, while delivering high starting torque, overload capability and superior reliability.The Super-E motor has an insulation system that meets the requirements of NEMA MG1 Part 31.4.4.2 for VFD (Variable Frequency Drive) use and is considered Not inverter.
Features
- 60 Hz design
- Locked DE bearing to allow mounting in any configuration
- Ball bearing
- Steel frame
- Gasketed conduit box
- NEMA Premium efficiency
- 3 year warranty
Applications
- Pumps
- Fans
- Conveyors
- Machine tools
- Gear reducers
- Other applications requiring a NEMA Standard motor
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor EM3219T-8, General Purpose Motor, 7-1/2 HP, 200 Volts, 20.0 Amps, 3 Phase, 3600 RPM, OPSB Enclosure, 184T Frame, Standard, Foot Mounted, 3632M Motor Type, Steel Frame | 1 | $1,620.85/each |
Description
Baldor Super-E Premium Efficient Totally Open General Purpose Motor
This motor is designed to meet or exceed the energy efficiency requirements of the United States for general purpose industrial motors, while delivering high starting torque, overload capability and superior reliability.The Super-E motor has an insulation system that meets the requirements of NEMA MG1 Part 31.4.4.2 for VFD (Variable Frequency Drive) use and is considered Not inverter.
Features
- 60 Hz design
- Locked DE bearing to allow mounting in any configuration
- Ball bearing
- Steel frame
- Gasketed conduit box
- NEMA Premium efficiency
- 3 year warranty
Applications
- Pumps
- Fans
- Conveyors
- Machine tools
- Gear reducers
- Other applications requiring a NEMA Standard motor
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | EM3219T-8 |
| Product Type | General Purpose Industrial Motor |
| Application | Material Handling, Machine Tool |
| Horsepower | 7-1/2 HP |
| Voltage | 200 Volts |
| Phase | 3 Phase |
| Frequency | 60 Hz |
| Synchronous Speed | 3600 RPM |
| Speed | 3450 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 20.0 Amps |
| Enclosure | OPSB |
| Motor Type | 3632M |
| Frame Size | 184T |
| Motor Standards | NEMA |
| Number of Poles | 2 |
| Pulley Face Code | Standard |
| Frame Material | Steel |
| Motor Lead Quantity/Wire Size | 3 @ 12 AWG |
| Overall Length | 15.00 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 88.50% |
| Duty Rating | CONT |
| Inverter Code | Not inverter |
| Auxillary Box | No |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Mounting Type | Food Mounting |
| Current | 20.0 A |
| Design Code | B |
| Drip Cover | No |
| Heater Indicator | No heater |
| KVA Code | L |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | No |
| Shaft Diameter | 1.125 in |
| Insulation Class | F |
| Power Factor | 91 |
| Pulley End Bearing Type | Ball Bearing |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | No |
| Thermal Device - Winding | No |
| Ambient Temperature | 40 °C |
| Agency Approvals | CSA, CSA, EEV, UR |
