Brand: Baldor
SKU: EHM2332T
Baldor EHM2332T, General Purpose HVAC Motor, 10 HP, 230/400 Volts, 14.1 Amps, 3 Phase, 1180 RPM, TEFC Enclosure, 256T Frame, Standard, 0960M Motor Type, Cast Iron Frame
Baldor Super-E Premium Efficient Totally Enclosed General Purpose Motor
This motors are specifically engineered with industry-driven designs to keep your air handling systems running smoothly, quietly, and efficiently, which means better system reliability and performance, with less maintenance.The Super-E motor has an insulation system that meets the requirements of NEMA MG1 Part 31.4.4.2 for VFD (Variable Frequency Drive) use and is considered Inverter Ready.
Features
- 60 Hz design
- Locked DE bearing to allow mounting in any configuration
- Ball bearing
- Cast Iron frame
- Gasketed conduit box
- NEMA Premium efficiency
- 3 year warranty
Applications
- Pumps
- Fans
- Conveyors
- Machine tools
- Gear reducers
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor EHM2332T, General Purpose HVAC Motor, 10 HP, 230/400 Volts, 14.1 Amps, 3 Phase, 1180 RPM, TEFC Enclosure, 256T Frame, Standard, 0960M Motor Type, Cast Iron Frame | 1 | $0.00/each |
Description
Baldor Super-E Premium Efficient Totally Enclosed General Purpose Motor
This motors are specifically engineered with industry-driven designs to keep your air handling systems running smoothly, quietly, and efficiently, which means better system reliability and performance, with less maintenance.The Super-E motor has an insulation system that meets the requirements of NEMA MG1 Part 31.4.4.2 for VFD (Variable Frequency Drive) use and is considered Inverter Ready.
Features
- 60 Hz design
- Locked DE bearing to allow mounting in any configuration
- Ball bearing
- Cast Iron frame
- Gasketed conduit box
- NEMA Premium efficiency
- 3 year warranty
Applications
- Pumps
- Fans
- Conveyors
- Machine tools
- Gear reducers
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | EHM2332T |
| Product Type | General Purpose HVAC Motor |
| Horsepower | 10 HP |
| Voltage | 230/400 Volts |
| Phase | 3 |
| Frequency | 60 Hz |
| Synchronous Speed | 1200 RPM |
| Speed | 1180 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 14.1 Amps |
| Enclosure | TEFC |
| Frame Size | 256T |
| Motor Type | 0960M |
| Motor Standards | NEMA |
| Number of Poles | 6 |
| Pulley Face Code | Standard |
| Frame Material | Cast Iron |
| Motor Lead Quantity/Wire Size | 9 @ 12 AWG |
| Overall Length | 23.28 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 91.00% |
| Duty Rating | CONT |
| Inverter Code | Inverter ready |
| Mounting Type | Foot Mounting |
| Auxillary Box | No |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Current | 30.0 A @ 208 V, 28.2 A @ 230 V, 14.1 A @ 460 V |
| Design Code | B |
| Drip Cover | No |
| Heater Indicator | No heater |
| KVA Code | H |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | No |
| Shaft Diameter | 1.625 in |
| Insulation Class | F |
| Power Factor | 72 |
| Pulley End Bearing Type | Ball Bearing |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | No |
| Thermal Device - Winding | No |
| Ambient Temperature | 40 °C |
| Agency Approvals | CSA, CSA, EEV, UR |
