Brand: Bell & Gossett
SKU: 179210LF
Bell & Gossett 179210LF, e9051S-ECM BF, e-90 Series, In-Line Centrifugal Pump with ECM Motor, 1/2 HP, 115 Volts, 1 Phase, 1765 RPM, 1-1/4AAB Size, 5" Impeller, Cast Iron Volute
Bell & Gossett e-90 In-Line Mounted Centrifugal Pump with ECM Motor
The e-90 pump is a versatile in-line pump that offers wide hydraulic coverage well suited for the small commercial HVAC market. Ths pump is designed to be mounted in the piping and can be installed either horizontally or vertically.
This pump comes with an Electronically Commutated Motor (ECM) which is a variable speed motor with motor mounted interface. The ECM motor adjusts motor speed to match flow and head requirements thus substantially reducing power consumption. The user interface allows for manual adjustment or remote control via 10 VDC input/output.
Features
- Long life and robust performance
- Robust EPR/carbon/silicon-carbide mechanical seal lowers maintenance and increases the life of the pump
- Energy savings
- Increased hydraulic efficiency
- Space savings and installation flexibility close-coupled
- Ability to mount horizontally and vertically
- Back-pull-out design allows the pump to be serviced without disturbing the piping
- NEMA standard motor 56J in ODP enclosure with vertical drip covers
- Excellent for boiler recirculation applications
Applications
- Hydronic heating and cooling
- Pressure boosting
- Refrigeration and heat exchanger circulation
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Bell & Gossett 179210LF, e9051S-ECM BF, e-90 Series, In-Line Centrifugal Pump with ECM Motor, 1/2 HP, 115 Volts, 1 Phase, 1765 RPM, 1-1/4AAB Size, 5" Impeller, Cast Iron Volute | 1 | $3,462.30/each |
Description
Bell & Gossett e-90 In-Line Mounted Centrifugal Pump with ECM Motor
The e-90 pump is a versatile in-line pump that offers wide hydraulic coverage well suited for the small commercial HVAC market. Ths pump is designed to be mounted in the piping and can be installed either horizontally or vertically.
This pump comes with an Electronically Commutated Motor (ECM) which is a variable speed motor with motor mounted interface. The ECM motor adjusts motor speed to match flow and head requirements thus substantially reducing power consumption. The user interface allows for manual adjustment or remote control via 10 VDC input/output.
Features
- Long life and robust performance
- Robust EPR/carbon/silicon-carbide mechanical seal lowers maintenance and increases the life of the pump
- Energy savings
- Increased hydraulic efficiency
- Space savings and installation flexibility close-coupled
- Ability to mount horizontally and vertically
- Back-pull-out design allows the pump to be serviced without disturbing the piping
- NEMA standard motor 56J in ODP enclosure with vertical drip covers
- Excellent for boiler recirculation applications
Applications
- Hydronic heating and cooling
- Pressure boosting
- Refrigeration and heat exchanger circulation
Specifications
| Brand | e-90 |
| Mfg. Number | Circulator |
| Product Type | Hydronic systems |
| Horsepower | 1/2 HP |
| Voltage | 115 Volts |
| Phase | 1 |
| Output KW | 60 Hz |
| Frequency | 1765 RPM |
| Speed | 1-1/4AAB |
| Current | 5" |
| Enclosure | ASTM #B584 |
| Frame Size | Cast iron |
| Motor Orientation | Stainless steel |
| Mounting Type | Flanged |
| Frame Material | 175 psi (12 bar) |
| Shaft Rotation | Open Drip Proof |
| Shaft Type | SM2129 |
| Ambient Temperature | 1.25" |
| Agency Approvals | e9051S-ECM BF |
