Brand: Baldor
SKU: CNEDM3546T
Baldor CNEDM3546T, AC Inverter/Vector Duty Motor, 1 HP, 230/460 Volts, 1.5 Amps, 3 Phase, 60 Hz, 1745 RPM, TENV Enclosure, 143TC Frame, C-Face, 3524M Motor Type, Steel Frame
Baldor AC Inverter/Vector Duty Motor
The Industrial electric motor is available for most general purpose applications and processes. However, some AC Variable Speed applications require constant torque at zero speed. Inverter/Vector motors are designed specifically for adjustable speed applications in a standard NEMA Frame motor. Additionally, the AC Inverter/Vector Motors can be ran across the line for bypass operation and can deliver a 1000:1 Speed Range in a standard TENV or TEBC Enclosure.
Features
- Extensive HP Range 1/3 - 500hp
- B Rise
- IEC
- 1000:1 CT
- Low Noise
- 841XL Features
- Cast iron Frame Construction
- Stock Availability
- Corona Free insulation
- Class F Insulation
- 200% torque overload for one minute at base speed
- Insulated Bearings
- Constant horsepower 1.5 times base speed
- Special Encoder provisions
Application
- Winders
- Positioning
- Extruders,
- Web Processing
- Oil Drilling
- Induction Servo Spindle
- Test Stands-low / high speed
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor CNEDM3546T, AC Inverter/Vector Duty Motor, 1 HP, 230/460 Volts, 1.5 Amps, 3 Phase, 60 Hz, 1745 RPM, TENV Enclosure, 143TC Frame, C-Face, 3524M Motor Type, Steel Frame | 1 | $1,961.58/each |
Description
Baldor AC Inverter/Vector Duty Motor
The Industrial electric motor is available for most general purpose applications and processes. However, some AC Variable Speed applications require constant torque at zero speed. Inverter/Vector motors are designed specifically for adjustable speed applications in a standard NEMA Frame motor. Additionally, the AC Inverter/Vector Motors can be ran across the line for bypass operation and can deliver a 1000:1 Speed Range in a standard TENV or TEBC Enclosure.
Features
- Extensive HP Range 1/3 - 500hp
- B Rise
- IEC
- 1000:1 CT
- Low Noise
- 841XL Features
- Cast iron Frame Construction
- Stock Availability
- Corona Free insulation
- Class F Insulation
- 200% torque overload for one minute at base speed
- Insulated Bearings
- Constant horsepower 1.5 times base speed
- Special Encoder provisions
Application
- Winders
- Positioning
- Extruders,
- Web Processing
- Oil Drilling
- Induction Servo Spindle
- Test Stands-low / high speed
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | CNEDM3546T |
| Product Type | AC Inverter/Vector Duty Motor |
| Horsepower | 1 HP |
| Voltage | 230/460 Volts |
| Phase | 3 |
| Frequency | 60 Hz |
| Synchronous Speed | 1800 RPM |
| Speed | 1745 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 1.5 Amps |
| Enclosure | TENV |
| Frame Size | 143TC |
| Motor Type | 3524M |
| Motor Standards | NEMA |
| Number of Poles | 4 |
| Pulley Face Code | C-Face |
| Frame Material | Steel |
| Motor Lead Quantity/Wire Size | 9 @ 18 AWG |
| Overall Length | 12.12 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 85.50% |
| Duty Rating | CONT |
| Inverter Code | Inverter ready |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Current | 3.0 A @ 208 V, 2.9 A @ 230 V, 1.5 A @ 460 V |
| Design Code | B |
| Drip Cover | No Drip Cover |
| Heater Indicator | No heater |
| KVA Code | M |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | None |
| Shaft Diameter | 0.875 in |
| Insulation Class | F |
| Power Factor | 76 |
| Pulley End Bearing Type | Sealed Bearing |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | NONE (OLD) |
| Thermal Device - Winding | None |
| Ambient Temperature | 40 °C |
| Agency Approvals | CCSA, US, CSA, EEV, UR |
