Brand: Baldor
SKU: CEDM3611T
Baldor CEDM3611T, AC VS Master Motor, 3 HP, 230/460 Volts, 4.2 Amps, 3 Phase, 60 Hz, 1760 RPM, TEFC Enclosure, 182TC Frame, C-Face, 3632M Motor Type, Steel Frame
Baldor AC VS Master Motors
Industrial electric motor is available for most general purpose applications and processes. However, some AC Variable Speed applications require constant torque down to zero speed. The VS Master motor is a standard NEMA Frame Motor that can deliver a 1000:1 Speed Range in a standard TEFC Enclosure (without the need for a Blower).
Features
- The VS Master product line is the most comprehesive,
- Nema frame size, totally encolosed product offered.
- Extensive HP Range 1/3-500hp
- B Rise
- IEC
- 1000:1 CT
- Low Noise
- 841XL Features
- Cast iron Frame Construction
- Stock Availability
- Corona Free insulation
- Class F Insulation
- 200% torque overload for one minute at base speed
- Insulated Bearings
- Constant horsepower 1.5 times base speed
- Special Encoder provisions
Application
- Center Winders
- Payoff reels
- Positioning
- Extruders
- Conveyers
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor CEDM3611T, AC VS Master Motor, 3 HP, 230/460 Volts, 4.2 Amps, 3 Phase, 60 Hz, 1760 RPM, TEFC Enclosure, 182TC Frame, C-Face, 3632M Motor Type, Steel Frame | 1 | $2,440.90/each |
Description
Baldor AC VS Master Motors
Industrial electric motor is available for most general purpose applications and processes. However, some AC Variable Speed applications require constant torque down to zero speed. The VS Master motor is a standard NEMA Frame Motor that can deliver a 1000:1 Speed Range in a standard TEFC Enclosure (without the need for a Blower).
Features
- The VS Master product line is the most comprehesive,
- Nema frame size, totally encolosed product offered.
- Extensive HP Range 1/3-500hp
- B Rise
- IEC
- 1000:1 CT
- Low Noise
- 841XL Features
- Cast iron Frame Construction
- Stock Availability
- Corona Free insulation
- Class F Insulation
- 200% torque overload for one minute at base speed
- Insulated Bearings
- Constant horsepower 1.5 times base speed
- Special Encoder provisions
Application
- Center Winders
- Payoff reels
- Positioning
- Extruders
- Conveyers
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | CEDM3611T |
| Product Type | AC VS Master Motor |
| Horsepower | 3 HP |
| Voltage | 230/460 Volts |
| Phase | 3 |
| Frequency | 60 Hz |
| Synchronous Speed | 1800 RPM |
| Speed | 1760 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 4.2 Amps |
| Enclosure | TEFC |
| Frame Size | 182TC |
| Motor Type | 3632M |
| Motor Standards | NEMA |
| Number of Poles | 4 |
| Pulley Face Code | C-Face |
| Frame Material | Steel |
| Motor Lead Quantity/Wire Size | 9 @ 16 AWG |
| Overall Length | 16.60 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 89.50% |
| Duty Rating | CONT |
| Inverter Code | Inverter duty |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Current | 9.0 A @ 208 V, 8.4 A @ 230 V, 4.2 A @ 460 V |
| Design Code | B |
| Drip Cover | No Drip Cover |
| Heater Indicator | No heater |
| KVA Code | K |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | None |
| Shaft Diameter | 1.125 in |
| Insulation Class | F |
| Power Factor | 75 |
| Pulley End Bearing Type | Ball |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | No Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | No |
| Thermal Device - Winding | None |
| Ambient Temperature | 40 °C |
| Agency Approvals | CCSA, US, CSA, EEV, UR |
