Brand: Baldor
SKU: ECP63665T-4
Baldor ECP63665T-4, 661XL Motor, 5 HP, 460 Volts, 6.6 Amps, 3 Phase, 1750 RPM, 60 Hz, TEFC Enclosure, 184T Frame, Standard, 0641M Motor Type, Cast Iron Frame
Baldor 661XL Motor
Baldor 661XL motors are designed for belt driven, Air Cooled Heat Exchanger applications in the Petroleum and Chemical Processing industries that require premium efficient motors designed to API 661 standards of 40,000 hours bearing life. They have all the features of our IEEE 841 motors.
Features
- Meets and or exceeds all the requirements of IEEE Std
- 841-2009 with the exception of Mobilith Grease which is required for best performance of he Roller Bearing design
Applications
- Belt driven, air cooled heat exchanger applications
Note: Picture is illustrative and may not reflect the actual product
Key Features:
The Following Was Added To Your Shopping Cart
| Item | Description | Qty | Unit Price |
|---|---|---|---|
|
Baldor ECP63665T-4, 661XL Motor, 5 HP, 460 Volts, 6.6 Amps, 3 Phase, 1750 RPM, 60 Hz, TEFC Enclosure, 184T Frame, Standard, 0641M Motor Type, Cast Iron Frame | 1 | $3,037.65/each |
Description
Baldor 661XL Motor
Baldor 661XL motors are designed for belt driven, Air Cooled Heat Exchanger applications in the Petroleum and Chemical Processing industries that require premium efficient motors designed to API 661 standards of 40,000 hours bearing life. They have all the features of our IEEE 841 motors.
Features
- Meets and or exceeds all the requirements of IEEE Std
- 841-2009 with the exception of Mobilith Grease which is required for best performance of he Roller Bearing design
Applications
- Belt driven, air cooled heat exchanger applications
Note: Picture is illustrative and may not reflect the actual product
Specifications
| Brand | Baldor |
| Mfg. Number | ECP63665T-4 |
| Product Type | 661XL Motor |
| Horsepower | 5 HP |
| Voltage | 460 Volts |
| Phase | 3 |
| Frequency | 60 Hz |
| Synchronous Speed | 1800 RPM |
| Speed | 1750 RPM |
| Speed Code | Single Speed |
| High Voltage Full Load Amps | 6.6 Amps |
| Enclosure | TEFC |
| Frame Size | 184T |
| Motor Type | 0641M |
| Motor Standards | NEMA |
| Number of Poles | 4 |
| Pulley Face Code | Standard |
| Frame Material | Cast Iron |
| Motor Lead Quantity/Wire Size | 3 @ 16 AWG |
| Overall Length | 15.93 in |
| Service Factor | 1.15 |
| Efficiency @ 100% Load | 89.50% |
| Duty Rating | CONT |
| Inverter Code | Inverter duty |
| Auxillary Box | No Auxillary Box |
| Base Indicator | Rigid |
| Bearing Grease Type | POLYREX EM (-20F +300F) |
| Current | 6.6 A |
| Design Code | B |
| Drip Cover | No Drip Cover |
| Heater Indicator | No heater |
| KVA Code | J |
| Motor Lead Exit | KO Box |
| Motor Lead Termination | Flying Leads |
| Rodent Screen | No |
| Shaft Diameter | 1.125 in |
| Insulation Class | F |
| Power Factor | 79 |
| Pulley End Bearing Type | Ball |
| Shaft Extension Location | Pulley End |
| Shaft Rotation | Reversible |
| Shaft Slinger Indicator | Shaft Slinger |
| Starting Method | Direct on line |
| Vibration Sensor Indicator | No Vibration Sensor |
| Thermal Device - Bearing | No |
| Thermal Device - Winding | No |
| Ambient Temperature | 40 °C |
| Agency Approvals | CSA, CSA, EEV, UR |
