Myers MPN Series Shallow Well Jet Pumps Buyers Guide & Review
Myers MPN series of shallow well jet pumps are not only corrosion and abrasion resistant, but this series is also ideal for wells with pumping levels of 25’ or less. The MPN series is self-priming after the pump housing is initially filled with water. This series features capacities to 18 GPM at 30 PSI. Pumps are available in 1/2, 3/4 and 1 HP models. Supplied with the industry standard 30-50 pressure switch setting.
Features
-
Fiberglass-reinforced thermoplastic body and seal plate
-
Engineered composite impeller is precision- molded for perfect balance and ultra-smooth for highest performance and efficiency
-
10-gauge steel base
-
Engineered composite nozzle, venturi, and diffuser
-
Quality Construction – Fiberglassreinforced thermoplastic body provides total corrosion resistance and high resistance to abrasion
-
Shallow-well jet has corrosion-resistant engineered composite nozzle and venturi
-
Engineered composite diffuser allows pump to prime faster, handle more air
-
Stainless steel shaft
-
Shielded, permanently lubricated dual heavy-duty bearings, extensively tested to ensure extended life and smooth, quiet operation
-
Dual voltage motors and are shipped at the 230 volt setting
-
Pre-set 30-50 PSI
-
Allows for cut-in pressure adjustment
-
Easy plug removal and access for ease of service and nozzle clean-out
-
New drain plug is ottom-mounted for easy draining and winterization
Applications
| MYERS MPN SERIES SHALLOW WELL JET PUMPS |

Myers MPN Series Shallow Well Jet Pumps
Model Comparison Chart
| Model |
Discharge (NPT) |
HP |
Voltage |
Phase |
GPM |
Max. Head |
| MPNC-10 |
1" |
1/2 |
115/230 |
1 |
8 |
177' |
| MPND-10 |
1" |
3/4 |
115/230 |
1 |
12 |
180' |
| MPNE-10 |
1" |
1 |
115/230 |
1 |
20 |
154' |
